The main pivot, called the king pin, is found in the steering device of a forklift. The very first design was a steel pin wherein the movable steerable wheel was attached to the suspension. In view of the fact that it could freely rotate on a single axis, it restricted the degrees of freedom of motion of the remainder of the front suspension. In the 1950s, the time its bearings were replaced by ball joints, more comprehensive suspension designs became obtainable to designers. King pin suspensions are nonetheless utilized on several heavy trucks as they have the advantage of being capable of carrying a lot heavier load.

The new designs of the king pin no longer restrict to moving similar to a pin. These days, the term may not even refer to an actual pin but the axis wherein the steered wheels pivot.

The KPI or likewise known as kingpin inclination may likewise be called the steering axis inclination or SAI. These terms define the kingpin if it is places at an angle relative to the true vertical line as viewed from the front or back of the lift truck. This has a vital effect on the steering, making it likely to return to the straight ahead or center position. The centre arrangement is where the wheel is at its highest position relative to the suspended body of the forklift. The motor vehicles weight has the tendency to turn the king pin to this position.

The kingpin inclination likewise sets the scrub radius of the steered wheel, which is the offset between projected axis of the tire's communication point with the road surface and the steering down through the king pin. If these items coincide, the scrub radius is defined as zero. Even though a zero scrub radius is possible without an inclined king pin, it needs a deeply dished wheel in order to maintain that the king pin is at the centerline of the wheel. It is much more practical to slant the king pin and use a less dished wheel. This also offers the self-centering effect.
