Fuses

A fuse comprises a wire fuse element or a metal strip of small cross-section compared to the circuit conductors, and is commonly mounted between two electrical terminals. Generally, the fuse is enclosed by a non-conducting and non-combustible housing. The fuse is arranged in series that can carry all the current passing throughout the protected circuit. The resistance of the element generates heat because of the current flow. The construction and the size of the element is empirically determined to make sure that the heat generated for a normal current does not cause the element to attain a high temperature. In instances where too high of a current flows, the element either rises to a higher temperature and melts a soldered joint within the fuse which opens the circuit or it melts directly.

An electric arc forms between the un-melted ends of the element whenever the metal conductor parts. The arc grows in length until the voltage needed to be able to sustain the arc becomes higher as opposed to the obtainable voltage within the circuit. This is what leads to the current flow to become terminated. Where alternating current circuits are concerned, the current naturally reverses course on each cycle. This method greatly enhances the fuse interruption speed. Where current-limiting fuses are concerned, the voltage required to sustain the arc builds up fast enough so as to essentially stop the fault current previous to the first peak of the AC waveform. This effect tremendously limits damage to downstream protected units.

The fuse is often made out of aluminum, zinc, copper, alloys or silver as these allow for stable and predictable characteristics. The fuse ideally, would carry its current for an indefinite period and melt fast on a small excess. It is important that the element must not become damaged by minor harmless surges of current, and must not change or oxidize its behavior after possible years of service.

In order to increase heating effect, the fuse elements could be shaped. In big fuses, currents may be separated between multiple metal strips. A dual-element fuse could comprise a metal strip that melts right away on a short circuit. This type of fuse can likewise have a low-melting solder joint that responds to long-term overload of low values compared to a short circuit. Fuse elements may be supported by nichrome or steel wires. This ensures that no strain is placed on the element however a spring may be integrated so as to increase the speed of parting the element fragments.

The fuse element is usually surrounded by materials that work to be able to speed up the quenching of the arc. Some examples consist of silica sand, air and non-conducting liquids.
